67CL32

CATEGORY

Sliding Doors

Description

The 67CL32 sliding door system is designed with versatility at its core, making it ideal for both new construction and renovation work. Its adaptable infill capacity from 24 to 32 mm allows for a modular approach, ensuring optimal performance in thermal insulation, acoustic comfort, and weather resistance.

Engineered to meet a wide range of project needs, the system supports multiple configurations and custom options—providing tailored solutions without compromising on style. Its sleek, modern design complements any architectural vision.

  • OVERVIEW
  • TECHNICAL DATA

Design features

  • Miter cut or straight cut dormant
  • Wallet-style opening
  • Simple, reinforced and super reinforced side and baffle uprights
  • Black or gray TPE or EPDM filling gaskets
  • 20 mm PMR threshold
  • Maximum weight per leaf of 200 kg (option 250 kg)

Options

  • Glazing range from 24 to 32 mm double glazing
  • Lock block with 1 to 4 locking points with anti-false operation
  • Single or two-tone with textured or anodized finishes
  • Unlimited number of leaves
  • Multi-rail option
  • Anti-burglary criterion: RC2
  • Corner sliding

Application type

  • Residential and non-residential projects, new and renovation.
  67CL32
Performances
Uw value W/m²K (Double glazing) : 1.4 W/m²K
Size limits
Max glass thickness (mm) : 24 to 32 mm
